New Zealand Frequency Spectrum Usage
KHz
9-90 Fixed, Maritime-Mobile and Radionavigation
90-120 Radionavigation (L0RAN C)
120-140 Restricted Radiation Devices (RRD)
140-165 Fixed, Maritime-Mobile and Radionavigation
165-190 Fixed, Radionavigation and Amateur
190-285 Aeronautical Beacons
285-325 Aeronautical and Maritime Beacons
325-415 Aeronautical Beacons
45-521 Maritime
521-1612 MF-AM Radio Broadcasting
1612-1690 Aeronautical Beacons, Broadcasting
1690-1800 Cordless Telephone (CTI/A-CTI/E Base Tx), Radio Buoys
1800-1950 Amateur 160 m Band
1950-2000 Radio Buoys
2000-2300 Fixed and Mobile
2300-2495 Broadcast 120 m Band ITropical)
2495-2850 Fixed and Mobile. Standard Frequency 2.5 MHz
2850-3155 Aeronautical
3155-3200 Fixed and Mobile
3200-3400 Broadcast 90 m Band ITropical)
3400-3500 Aeronautical
3500-3900 Amateur 80 m Band
3900-4000 Broadcast 75 m Band
4000-4438 Maritime
4438-4650 Fixed and Mobile
4650-4750 Aeronautical
4750-5060 Broadcast 60 m Band (Tropical), Standard Frequency 5 MHz
5060-5480 Fixed and Mobile
5480-5730 Aeronautical
5730-5900 Fixed and Mobile
5900-6200 Broadcast 49 m Band
6200-6525 Maritime
6525-7565 Aeronautical
6765-6795 Industrial, Scientific and Medical (ISM) and RRD
6795-7000 Fixed and Mobile
7000-7100 Amateur 40 m Band
7100-7350 Broadcast 41 m Band, Amateur (7100-7300)
7350-8100 Fixed and Mobile
8100-8815 Maritime
8815-9040 Aeronautical
9040-9400 Fixed
9400-9900 Broadcast 31 m Band
9900-10000 Fixed and Standard Frequency 10 MHz
MHz
10.00-10.100 Aeronautical
10.100-10.150 Amateur 30 m Band
10.150-11.175 Fixed
11.175-11.400 Aeronautical
11.400-11.600 Fixed
11.600-12.100 Broadcast 25 m Band
12.100-12.230 Fixed
12.230-13.200 Maritime
13.200-13.360 Aeronautical
13.360-13.550 Fixed and Mobile
13.550-13.570 ISM (13.560 MHz) and RRD
13.570-13.870 Broadcast 22 m Band
13.870-14.000 Fixed
14.000-14.350 Amateur 20 m Band
14.350-15.000 Fixed and Standard Frequency 15 MHz
15.000-15.100 Aeronautical
15.100-15.800 Broadcast 19m Band
15.800-16.360 Fixed
16.360-17 410 Maritime
17 410-17480 Fixed
17~480-17 900 Broadcast 16 m Band
17 900-18.030 Aeronautical
18.030-18.068 Fixed
18.068-18.168 Amateur 17 m Band
15.165-15.780 Fixed
15.780-18.900 Maritime
18.900-19.020 Broadcast 15 m Band
19.020-19.680 Fixed
19.680-19.800 Maritime
19.800-21.000 Fixed and Standard Frequency 20 MHz
21.000-21.450 Amateur 15 m Band
21.450-21.850 Broadcast 13 m Band
21.850-21.870 Fixed
21.870-22.000 Aeronautical
22.000-22.855 Maritime
22.855-23.200 Fixed
23.200-23.350 Aeronautical
23.350-24.890 Fixed and Mobile
24.890-24.990 Amateur 12 m Band
24.990-25.070 Fixed and Mobile, Standard Frequency 25 MHz
25.070-25.210 Maritime
25.210-25.550 Fixed and Mobile
25.550-25.670 Astronomy
25.670-26.10 Broadcast 11 m Band
26.100-26.175 Maritime
26.175-26.300 Fixed and Mobile
==========================================================
26.300- Citizen Radio Service (40 channels)
26.800- Fixed and Mobile
26.950- ISM (27.120 MHz) and RRD)
27 300- Fixed and Mobile
28.000- Amateur 10 m Band
29.700- RRD (Restricted Radiation Devices)
30.000- Cordless Telephone (CTl Base Tx)
30.800- Fixed and Mobile
31.300- RRD
31.600- Fixed and Mobile, TV Sound IF 33.40 MHz
34.200- Cordless Telephone (CTl Base Tx)
34.600- Fixed and Mobile
35.400- ISM (37 500 MHz and RRD
37 200- Fixed and Mobile, TV Vision IF 38.90 MHz
39.700- Cordless Telephone (CTl Portable Tx)
40.500- ISM (40.680 MHz) and RRD
40.800- Fixed and Mobile .
44-51 VHF TV Channel 1
51-53 Amateur
53.-54 Fixed, Mobile and Amateur
54-61 VHF TV Channel 2
61-68 VHF TV Chann~13
68.0000- Not Allocated
70.0000- Fixed " M' Band (Alpha Tx)
71.8000- Not Allocated
72.0000- RRD
73.000- Fixed " M' Band (Beta Tx)
74.800- Aeronautical Marker Beacons
75.200- Land Mobile (Emergency Services-Base Tx)
76.200- Not Allocated
78.100- Land Mobile (Emergency Services-Mobile Tx)
79.100- Not Allocated
88.000- Guardband
88.200- VHF-FM Sound Broadcast (Low Power)
88.800- VHF-FM Sound Broadcast
100.200- RRD, Wireless Public Address Systems
100.800- Guardband
100.990- Land Mobile "B" Band (Mobile Tx)
104.01875- Land Mobile Single Frequency
104.96875- Land Mobile "B" Band (Base Tx)
108.0000- Aeronautical ILS Localiser
112.0000- Aeronautical VQR Beacons
117.9750- Aeronautical Communications (R)
132.0125- Aeomautical Repeater (OR) (Base Tx)
132.5875- Aeronautical Communications (OR)
135.4125- Aeronautical Repeater (OR) (Mobile Tx)
136.0000- Aeronautical Communications (R)
137.0000- Moblle-Satellite and Meteomlogical Satelite (S-E)
138.0000- Land Mobile (Emergency Services.--Mobile Tx)
140.5000- Land MobIle Single Frequency
141.0000- Land Mobile (Emergencv Services.--Base Tx)
143.5000- Land Mobile Simplex Frequency
144.0000- Amateur 2m Band
148.0000- Land Mobile (Civil Defence-Mobile Tx)
148.5000- Paging
148.8125- Land Mobile Simplex Frequency
149.0625- Paging
149.3875- Land Mobile (Base Tx)
(This spectrum was also allocated to the Mobile Satelite Service (E-S) at the
1992 WARC with specific intended application worldwide for LEO satelite
systems.
148.9000- Radionav-Satelite (TRANSIT) Moblle-SatelUte (E-S)
150.0500- Land Mobile Simplex Frequency
151.0000- Land Mobile "E" Band (Base Tx)
153.4125- Land Mobile Simplex Frequency
153.59375- Land Mobile "E" Band (MobIle Tx)
156.0000- Maritime VHF (Mobile Tx)
156.3625- Maritime Mobile Single Frequency
156.8875- Maritime VHF (MobIle Tx)
157 5875- Wide Area Paging
158.0625- Land Mobile (Special Services-Mobile Tx)
158.5875- Land Mobile Simplex Frequency
158.7875- Land Mobile Radio Repeater
160.1000- RRD
160.6000- Maritime VHF (Base Tx)
160.9625- Land Mobile (Special Services-Base Tx)
161.4875- Maritime VHF (Base Tx)
162.2000- Land Mobile (Base Tx)lFixed (Alpha Tx)
165.7000- Land MobIle Single Frequency
166.8000- Land Mobile (Mobile Tx7Fixed (Beta Tx)
170.3000- Land Mobile Single Frequency
171.0000- Land Mobile Radio Repeater
172.0000- Not Allocated
174-181 VHF TV Channel 4
181-188 VHF TV Channel 5
188-195 VHF TV Channel 6
195-202 VHF TV Channel 7
202-209 VHF TV Channel 8
209-216 VHF TV Channel 9
216-223 VHF TV Channel l0
223-230 VHF TV Channel 11
230.00-300.00 Fixed and Mobile
300.00-305.00 Fixed, Mobile and RRD
305.00-312.00 Fixed and Mobile
312.00-315.00 Mobile-Satelite (E.S)
315.00-328.60 Fixed and Mobile
328.60-335.40 Aeronautical ILS Glidepath
335.40-387.00 Fixed and Mobile
387.00-390.00 Mobile-Satelite (E.S)
390.00-399.00 Fixed and Mobile
399.90-400.05 Radionavigation Satelite (TRANSIT)
400.05-400.15 Standard Frequency Satelite
400.15-401.00 Meteorological, Meteorological-Satelite (S-E)
401.00-404.00 Meteorological
|
